| Technical Data Sheet | ||
| ● | Frequency Range | 6.0 ~ 26.5GHz |
| ● | Phase Difference | 180° |
| ● | Nominal Split | 3.01dB |
| ● | Insertion Loss | ≤1.8dB |
| ● | VSWR | ≤1.7:1 |
| ● | Amplitude Balance | ≤±0.8dB |
| ● | Phase Balance | ≤±15° |
| ● | Isolation | ≥16dB |
| ● | Impedance | 50 Ohms |
| ● | Power Handling | Average: 20W Max. ; Peak: 100W Max. |
| ● | Connectors | 2.92mm(K)-Female |
| ● | Surface Finish | Painted Black |
