| Technical Data Sheet | ||
| ● | Way | 2 |
| ● | Frequency Range | 2.0～26.5GHz |
| ● | Insertion Loss | ≤2.0dB (Does not Contain theory loss 3 dB) |
| ● | VSWR | IN: ≤1.7:1 ; OUT≤1.5:1 |
| ● | Isolation | ≥15dB |
| ● | Amplitude Balance | ≤±0.5dB |
| ● | Phase Balance | ≤±5° |
| ● | Power Handling | Forward ≤10Watt ; Reversed ≤1Watt |
| ● | Operating Temperature | -45～+85℃ |
| ● | Surface Finish | Black Paint |
| ● | Connectors | SMA-Female |
| ● | Impedance | 50 ohms |
| Test Curve | ||
