Technical Data Sheet
●	Center Frequency(F0)	14GHz
●	Pass Band Frequency	10～18GHz
●	Pass Band Insertion Loss	≤1.0dB
●	Pass Band VSWR	≤1.8:1
●	Stop Band Rejection	≥50dB @ DC～8.5GHz ≥45dB @ 19.5～22GHz
●	Impedance	50 ohms
●	Power	≤2W
●	Connectors	SMA-Female (Stainless Steel)
●	Surface Finish	Black Paint
●	Temperature Range	-40℃～+80℃
Test Curve
