| Technical Data Sheet | |||
| ● | Center Frequency(F0) | 12.02GHz | |
| ● | Pass Band Frequency | 10.6 ~ 13.44GHz | |
| ● | Pass Band Insertion Loss | ≤2.0dB | |
| ● | Pass Band Ripple | ≤0.5dB | |
| ● | Pass Band VSWR | ≤1.5:1 | |
| ● | Stop Band Rejection | ≥60dB @ DC ~ 9.5GHz | ≥60dB @ 15 ~ 20GHz |
| ● | Impedance | 50 Ohms | |
| ● | Power | 2W Max. | |
| ● | Connectors | SMA-Female | |
| ● | Surface Finish | Painted Black | |
| ● | Temperature Range | -30℃ ~ +70℃ | |
| Test Curve | |||
