| Technical Data Sheet | |||
| ● | Center Frequency(F0) | 915MHz | |
| ● | Pass Band Frequency | 902 ~ 928MHz | |
| ● | Pass Band Insertion Loss | ≤2.0dB | |
| ● | Pass Band VSWR | ≤1.3:1 | |
| ● | Stop Band Rejection | ≥40dB @ DC ~ 892MHz | ≥40dB @ 938 ~ 2000MHz |
| ● | Impedance | 50 Ohms | |
| ● | Power Handling | 20W Max. | |
| ● | Connectors | N-Female | |
| ● | Surface Finish | Painted Black | |
| ● | Temperature Range | -30℃ ~ +70℃ | |
| Test Curve | |||
