| Technical Data Sheet | ||
| ● | Center Frequency(F0) | 2140MHz |
| ● | Pass Band Frequency | 2080 ~ 2200MHz |
| ● | Pass Band Insertion Loss | ≤1.0dB |
| ● | Pass Band VSWR | ≤1.3:1 |
| ● | Stop Band Rejection | ≥50dB @ Fc±80MHz (DC ~ 2000MHz , 2280 ~ 4000MHz) |
| ● | Impedance | 50 Ohms |
| ● | Power Handling | 20W Max. |
| ● | Connectors | SMA-Female |
| ● | Surface Finish | Painted Black |
| ● | Temperature Range | -30℃ ~ +70℃ |
| Test Curve | ||
