  • 368-372MHz Cavity Band Pass Filter
368-372MHz Cavity Band Pass Filter

368-372MHz Cavity Band Pass Filter

  • P/N： HXLBQ-DTA315
  • Pass Band Frequency：368-372MHz
  • Stop Band Rejection：≥40dB
  • Connectors：SMA-Female
  • Product description: Small size and high cost performance_Low standing wave and low insertion loss_Inhibition of high__Ultra Wide Band Filter_Narrow Band Filter_Suspended Stripline Filter_Cavity Filter_LC Filter_Interdigi
  • PDF technical index download
Technical Data Sheet
● Center Frequency(F0) 370MHz
● Pass Band Frequency 368 ~ 372MHz
● Pass Band Insertion Loss ≤1.0dB
● Pass Band Ripple ≤0.3dB
● Pass Band VSWR ≤1.3:1
● Stop Band Rejection ≥50dB @ DC ~ 348MHz ≥50dB @ 392 ~ 1000MHz
● Impedance 50 Ohms
● Power Handling 20W Max.
● Connectors SMA-Female
● Surface Finish Painted Black
● Temperature Range -30℃ ~ +70℃
Test Curve
