| Technical Data Sheet | |||
| ● | Center Frequency(F0) | 5650MHz | |
| ● | Pass Band Frequency | 5390 ~ 5910MHz | |
| ● | Pass Band Insertion Loss | ≤1.8dB | |
| ● | Pass Band Ripple | ≤1.0dB | |
| ● | Pass Band VSWR | ≤1.22:1 | |
| ● | Stop Band Rejection | ≥40dB @ DC ~ 5290MHz | ≥40dB @ 6010 ~ 11000MHz |
| ● | Impedance | 50 Ohms | |
| ● | Power Handling | 5W Max. | |
| ● | Connectors | ø0.5*2mm PIN (SMA-Female Removable) | |
| ● | Surface Finish | The Original Silver Color | |
| ● | Temperature Range | -30℃ ~ +70℃ | |
| Test Curve | |||
