Technical Data Sheet
●	Center Frequency(F0)	14GHz
●	Pass Band Frequency	10 ~ 18GHz
●	Pass Band Insertion Loss	≤2.0dB
●	Pass Band Ripple	≤1.2dB
●	Pass Band Return Loss	≥17dB
●	Stop Band Rejection	≥80dB @ DC ~ 7.7GHz	≥50dB @ 18.5 ~ 18.8GHz
		≥50dB @ 7.7 ~ 8.8GHz	≥80dB @ 18.8 ~ 25.5GHz
●	Impedance	50 Ohms
●	Power Handling	5W Max.
●	Connectors	ø0.5*2mm PIN (SMA-Female Removable)
●	Surface Finish	Painted Black
●	Temperature Range	-30℃ ~ +70℃
Test Curve
