Technical Data Sheet
●	Center Frequency(F0)	1900MHz
●	Pass Band Frequency	1885 ~ 1915MHz
●	Pass Band Insertion Loss	≤1.5dB
●	Pass Band Ripple	≤0.6dB
●	Pass Band VSWR	≤1.22:1
●	Stop Band Rejection	≥40dB @ DC ~ 1865MHz	≥40dB @ 1935 ~ 4000MHz
●	Impedance	50 Ohms
●	Power Handling	40W Max.
●	Connectors	SMA-Female
●	Surface Finish	Painted Black
●	Temperature Range	-30℃ ~ +70℃
Test Curve
