Technical Data Sheet
●	Center Frequency(F0)	725.5MHz
●	Pass Band Frequency	703 ~ 748MHz
●	Pass Band Insertion Loss	≤1.5dB
●	Pass Band Ripple	≤0.7dB
●	Pass Band VSWR	≤1.22:1
●	Stop Band Rejection	≥40dB @ DC ~ 693MHz	≥40dB @ 758 ~ 2000MHz
●	Impedance	50 Ohms
●	Power	20W Max.
●	Connectors	SMA-Female
●	Surface Finish	Painted Black
●	Temperature Range	-30℃ ~ +70℃
Test Curve
