Technical Data Sheet
●	Center Frequency(F0)	8.75GHz
●	Pass Band Frequency	8.0 ~ 9.5GHz
●	Pass Band Insertion Loss	≤1.0dB
●	Pass Band Ripple	≤0.5dB
●	Pass Band Return Loss	≥20dB
●	Stop Band Rejection	≥80dB @ DC ~ 7.35GHz	≥50dB @ 9.9 ~ 10.1GHz
		≥50dB @ 7.35 ~ 7.6GHz	≥80dB @ 10.1 ~ 26GHz
●	Impedance	50 Ohms
●	Power Handling	5.0W Max.
●	Connectors	SMA-Female
●	Surface Finish	Painted Black
Test Curve
