Technical Data Sheet
●	Center Frequency(F0)	10.45GHz
●	Pass Band Frequency	9.7 ~ 11.2GHz
●	Pass Band Insertion Loss	≤1.2dB
●	Pass Band Ripple	≤0.6dB
●	Pass Band Return Loss	≥20dB
●	Stop Band Rejection	≥80dB @ DC ~ 9.05GHz	≥50dB @ 11.6 ~ 11.85GHz
		≥50dB @ 9.05 ~ 9.3GHz	≥80dB @ 11.85 ~ 22GHz
●	Impedance	50 Ohms
●	Power Handling	5.0W Max.
●	Connectors	SMA-Female
●	Surface Finish	Painted Black
Test Curve
